Airtac 2KWL Fluid Solenoid Valve 2KWL03008A
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03008A Fluid Solenoid Valve Specifications
- Model: 2KWL03008A
- Type: 2-position, 3-way normally closed (direct-acting)
- Fluid medium: Water, air, light oil (ISO VG32 or lower)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.02–1.0 MPa (liquid), 0.05–1.0 MPa (air)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Weight: 450g ±5% (excluding coil)
- Dimensions: 80mm(L) × 50mm(W) × 100mm(H)
- Body material: Brass (CuZn39Pb3) with nickel plating
- Seal material: EPDM rubber (standard), optional FKM
- Temperature range: -5℃ to 80℃ (EPDM), -5℃ to 150℃ (FKM)
- Flow rate: 180L/min (air), 45L/min (water) @ 0.5MPa
- Response time: ≤30ms (excitation), ≤50ms (de-excitation)
- Protection rating: IP67 (coil), IP65 (valve body)
- Manual override: Built-in emergency switch
High-flow solenoid valve with corrosion-resistant construction, featuring zero differential pressure operation capability. The brass body with multi-layer sealing structure prevents leakage in high-vibration environments. Compatible with both pneumatic and hydraulic systems, rated for 1 million cycles minimum.
- Industrial water treatment systems (reverse osmosis controls)
- Beverage dispensing equipment flow control
- Coolant circulation in CNC machining centers
- Compressed air line switching in automotive assembly
- Hydraulic lift gate controls
Installation guidelines:
Install with flow direction arrow aligned. For liquid applications, maintain minimum 2s ON/OFF intervals.
Use vibration-damping mounts in mobile equipment. Flush system before initial use (≥5 cycles).
| Property | Property Value |
|---|---|
| sku | 2KWL03008A |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
