Airtac 2KWL Fluid Solenoid Valve 2KWL03008B
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03008B Fluid Solenoid Valve Technical Details
- Model: 2KWL03008B
- Type: 2-position 5-way direct-acting (monostable)
- Port configuration: 1/4" BSPP (G1/4)
- Effective area: 18mm² (pilot port), 30mm² (main port)
- Operating pressure: 0.05–1.0 MPa
- Voltage variants: DC12V (3W), DC24V (3.5W), AC110V (5VA), AC220V (5VA)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Fluid compatibility: Air, inert gases (filtered oil mist ≤1,000ppm)
- Seal materials: HNBR (hydrogenated nitrile) main seals, FKM optional
- Ambient temperature: -10℃ to 60℃ (non-freezing)
- Weight: 450g ±5% (with coil)
- Dimensions: 70mm(L) × 50mm(W) × 90mm(H)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (4 full threads)
- Certification: RoHS compliant, CE marked
High-flow solenoid valve with precision-machined stainless steel spool, designed for industrial automation requiring rapid cycling. Features double-chamber design for reduced pressure loss and 360° vibration resistance. Requires 5μm filtration (40μm for temporary use). Lubricator recommended for dry air systems.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging systems
- Coolant flow switching in CNC machining centers
- Air blow cleaning circuits in food processing equipment
- Pressure regulation in industrial washing machines
Maintenance protocol:
Perform monthly manual override tests using the mechanical override button.
When installing, maintain ≥25mm clearance below valve for condensate drainage.
Use copper-free anti-seize compound on threads.
| Property | Property Value |
|---|---|
| sku | 2KWL03008B |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
