Airtac 2L Solenoid Valve 2L03006AI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006AI Technical Specifications
- Model: 2L03006AI
- Type: 5/2-way single solenoid control (dual-pressure operated)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Manual override: Built-in emergency manual operator
- Flow capacity: 650 l/min (ANR) at 0.5 MPa
- Weight: 220g ±5% (excluding connectors)
- Dimensions: 58mm(L) × 34mm(W) × 78mm(H)
- Body material: Reinforced PBT with stainless steel core
- Seal material: Heat-resistant NBR (optionally available in FKM)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Cycle life: ≥10 million operations
High-flow bistable solenoid valve with position memory function, featuring low-hysteresis operation and energy-saving design. The dual-coil structure allows momentary pulse control with automatic position retention. Compatible with vacuum applications when paired with ejectors. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
- Textile machinery air circuit switching
- Cleanroom-compatible medical device controls
- Packaging machine vacuum pickup systems
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 20mm clearance from adjacent components for heat dissipation.
Use copper-free anti-seize compound on threaded ports during installation.
Critical note:
Not suitable for explosive atmospheres. Always install downstream
moisture separator when used in high-humidity environments (>80% RH).
| Property | Property Value |
|---|---|
| sku | 2L03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
