Airtac 2L Solenoid Valve 2L03006C
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006C Technical Details
- Model Number: 2L03006C
- Valve Type: 2-position 3-way, Normally Closed (Direct-acting)
- Port Thread: G1/8 (ISO228/1 standard)
- Operating Pressure Range: 0.05–0.7 MPa (7–100 PSI)
- Voltage Variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Effective Flow Rate: 200 L/min (ANR) at 0.5 MPa
- Ambient Temperature: -5℃ to 60℃ (non-freezing)
- Fluid Temperature: 0℃ to 60℃
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Body Material: Reinforced PBT resin with UL94 V-0 flame rating
- Electrical Protection: Class F insulation (155℃)
- Duty Cycle: 100% continuous operation
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 215g ±5g (including connector)
- Dimensions: 53mm(H) × 30mm(W) × 42mm(D) (manual override protrudes 8mm extra)
- Protection Rating: IP67 (dustproof/water immersion resistant)
- Port Alignment: 3-port manifold style (IN/OUT/AUX)
High-response solenoid valve optimized for low-power systems, featuring brass internal flow paths for enhanced corrosion resistance. The dual-coil structure enables stable operation in voltage fluctuation environments (±10% tolerance). Includes manual override button for system debugging and emergency control. Requires 5μm filtration for optimal performance.
- Beverage dispensing machine flow control
- Textile machinery pneumatic actuators
- Semiconductor wafer handling robots
- Electric vehicle battery cooling systems
- Pharmaceutical blister packaging lines
Installation guidelines:
Mount with DIN43650 Form A connector facing downward to prevent debris accumulation.
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Use copper-free anti-seize compound on threads for aluminum manifolds.
| Property | Property Value |
|---|---|
| sku | 2L03006C |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
