Airtac 2L Solenoid Valve 2L03006EI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006EI Technical Details
- Model: 2L03006EI
- Type: 5/2-way single solenoid control (double solenoid 2L03006ED optional)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V/24V, AC110V/220V (50/60Hz)
- Flow coefficient (Cv): 1.6
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal materials: HNBR/NBR (standard), FKM available for high-temp versions
- Ambient temperature: -5℃ to 60℃ (standard), -20℃ to 80℃ (special order)
- Weight: 285g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 85mm(H)
- Port thread depth: 12mm
- Protection class: IP67 (coil), IP40 (valve body)
- Electrical connection: DIN43650 Form A (direct wiring kit optional)
High-flow proportional solenoid valve with aluminum alloy body and manual override. Features zero-pressure differential start capability and surge protection circuitry. Requires ISO 8573-1:2010 Class 3.4.3 compressed air (40μm filtration recommended). Compatible with vacuum applications when using V-series seals.
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC tool changers
- Textile machinery tension control
- Semiconductor wafer handling robots
- Beverage filling station pneumatic circuits
Installation guidelines:
Mount with 15mm minimum clearance on all sides for heat dissipation.
Use copper-free anti-seize compound on threaded ports.
For horizontal mounting, orient exhaust ports downward to prevent debris accumulation.
Maintenance note:
Replace internal filters every 5,000 operation hours in normal conditions.
When using in explosive atmospheres, pair with ATEX-certified coils (2L-EX series).
| Property | Property Value |
|---|---|
| sku | 2L03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
