Airtac 2L Solenoid Valve 2L03008BI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008BI Technical Details
- Model: 2L03008BI
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 180g ±5g
- Dimensions: 50mm(L) × 30mm(W) × 70mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 100℃)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Protection class: IP67 (dust-tight and protected against temporary immersion)
- Flow capacity: 800 l/min (ANR) at 0.5MPa
- Port thread depth: 9.5mm (minimum engagement)
High-flow directional control valve with reinforced coil insulation (Class F) for continuous duty cycles. Features dual-color LED status indicator (red/green) and surge protection circuitry. Designed for ISO 15407-1 compliant pneumatic systems. Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 4.4.3).
- Automated assembly line actuators
- Plastic injection molding machine clamps
- Textile machinery cylinder control
- Food processing pneumatic circuits (oil-mist lubrication required)
- Semiconductor wafer handling robots
Mounting guidelines:
Install with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance below valve for exhaust airflow.
Use copper-free anti-seize compound on threads for stainless steel ports.
| Property | Property Value |
|---|---|
| sku | 2L03008BI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
