Airtac 2L Solenoid Valve 2L03008E
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008E Technical Details
- Model: 2L03008E
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow capacity: 750 Nl/min (Cv=1.3)
- Weight: 450g ±5% (including coil)
- Dimensions: 55mm(L) × 45mm(W) × 78mm(H)
- Seal materials: HNBR (main seals), FKM (optional)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with manual override, featuring brass main body and corrosion-resistant plating. Designed for double-acting cylinder control with 5 ports/2 positions configuration. Includes LED status indicator and surge protection diode. Requires 5μm filtration with automatic drain.
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery tension control
- Food processing pneumatic systems
- Automotive tire assembly equipment
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use flexible tubing connections to minimize vibration transfer.
Lubricate every 5 million cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2L03008E |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
