Airtac 2L Solenoid Valve 2L03008F
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008F Technical Specifications
- Model: 2L03008F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 180g ±5g (excluding connector)
- Dimensions: 50mm(L) × 35mm(W) × 65mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with anti-stick additives
- Ambient temperature: -5℃ to 60℃ (with 20% derating above 40℃)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (pressurized), ≤25ms (exhaust)
- Port thread depth: 10mm (minimum engagement 7.5mm)
- Protection class: IP67 (dustproof & temporary immersion)
- Mounting orientation: Any (horizontal preferred for drainage)
High-flow 5-port pneumatic valve engineered for sequential control systems requiring precise directional switching. Features dual-pressure capability with optimized flow paths (Cv=0.25) and gold-plated terminals for corrosion resistance. The encapsulated coil design meets IEC60068-2-6 vibration standards (10-150Hz, 1.5mm amplitude). Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automotive welding fixture sequencing
- Plastic injection molding machine ejectors
- Bottle capping system actuators
- CNC tool changer mechanisms
- Food processing pneumatic circuits (NSF-H1 grease compatible)
Maintenance protocol:
Install upstream 5μm filter regulator. For continuous operation,
perform manual cycling monthly during downtime. Use Loctite 243
(medium strength) for port thread sealing. Avoid silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | 2L03008F |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
