Airtac 2L Solenoid Valve 2L05010A
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05010A 5/2-Way Solenoid Valve Technical Details
- Model: 2L05010A (2L series)
- Valve type: 5-port 2-position (5/2-way) double solenoid
- Port thread: G1/4 (BSPP) with NPT optional
- Operating pressure range: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage variants: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Power consumption: 2.5W (DC) / 4.5VA (AC)
- Flow capacity: 850 l/min (Cv=1.2)
- Response time: ≤15ms (actuation), ≤20ms (reset)
- Seal material: Heat-resistant NBR (Nitrile)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 310g ±5% (excluding cables)
- Dimensions: 54mm(W) × 45mm(H) × 125mm(L)
- Mounting: Direct piping or sub-base (ISO 5599-1 compatible)
- Protection class: IP67 (dustproof/water-resistant)
- Porting pattern: ISO 5599-1 standard (interchangeable with major brands)
High-flow proportional solenoid valve engineered for bidirectional cylinder control in industrial automation. Features dual coil latching design with manual override and surge suppression. The aluminum alloy body with hard anodizing resists chemical corrosion in harsh environments. Requires 5μm filtration (40μm max) with lubricated air (ISO 8573-1 class 4).
- Pneumatic pressurization systems in automotive assembly
- Rotary actuator control for material handling robots
- Plastic injection molding machine sequencing
- Packaging line diverters and clamping mechanisms
- Semiconductor wafer handling equipment
Operational guidance:
Maintain ≤85% rated voltage during continuous operation. For vertical mounting,
install coil axis horizontally. Use locking connectors (M12×1) for vibration-prone
environments. Lubricate every 5 million cycles under normal load.
| Property | Property Value |
|---|---|
| sku | 2L05010A |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
