Airtac 2L Solenoid Valve 2L05010AI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05010AI Solenoid Valve Technical Details
- Model: 2L05010AI
- Type: 5-port/2-position, center closed (pilot-operated)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage variants: DC24V (±10%), AC220V (50/60Hz)
- Weight: 280g ±5g
- Dimensions: 62mm(L) × 37mm(W) × 37mm(H)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Power consumption: 1.5W (DC) / 2.2VA (AC)
- Flow coefficient (Cv): 0.8
- Response time: ≤15ms (at 0.5MPa)
- Protection class: IP65 (dustproof & water jet resistant)
High-speed switching valve with compact pancake design, featuring dual electrical connectors for flexible wiring. The aluminum alloy body ensures heat dissipation and vibration resistance. Includes manual override function for emergency operation. Requires 5μm filtered compressed air with lubrication (ISO 8573-1 class 3.4.3).
- Small-scale automation workstations
- Beverage filling machine actuators
- Textile machinery tension control
- Pharmaceutical blister packaging systems
- Automatic door locking mechanisms
Mounting guidance:
Install with M5 mounting screws (max torque 1.2N·m). Maintain 50mm clearance
below valve for maintenance access. Lubricate every 2,000 operating hours
using ISO VG32 turbine oil. Avoid horizontal installation to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | 2L05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
