Airtac 2L Solenoid Valve 2L05010E
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05010E 2-Way Solenoid Valve Specifications
- Model: 2L05010E
- Type: 5-port 2-position (2L series, pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Port thread depth: 10mm (minimum engagement)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -5℃ to 60℃ (fluid/ambient)
- Weight: 350g ±5% (without coil)
- Dimensions: 65mm(L) × 35mm(W) × 75mm(H)
- Response time: ≤20ms (at rated voltage)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Protection rating: IP65 (coil protection standard)
- Power consumption: ≤2.2W (DC24V model)
High-flow solenoid valve with optimized spool structure for reduced pressure loss. Features anti-vibration design (up to 10Hz/1.5mm amplitude) and manual override capability. Requires ISO 8573-1:2010 class 3 compressed air (max 40μm particle size). Compatible with dry air/lubricated systems.
- Automated production line actuators
- Pneumatic clamping systems
- Food packaging machine sequencing
- Medical gas control panels
- Automotive assembly tooling
Installation guidelines:
Mount with vibration-damping pads in high-shock environments.
Maintain 50mm clearance below valve for maintenance access.
Use copper-free lubricants if required. Maximum allowable
pipe torque: 12N·m.
| Property | Property Value |
|---|---|
| sku | 2L05010E |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
