Airtac 2LH Fluid Solenoid Valve 2LH03006AI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006AI Fluid Solenoid Valve Specifications
- Model: 2LH03006AI
- Type: 2-position, 3-way direct-acting (Normally Closed)
- Port size: PT1/8 (G1/8 optional)
- Fluid compatibility: Air, water, light oils (ISO VG32 or lower)
- Operating pressure: 0.05–1.0 MPa
- Max pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%), AC110V (±15%), AC220V (±15%)
- Power consumption: 1.8W (DC), 3.5VA (AC)
- Response time: ≤15ms (open/close)
- Weight: 320g ±5%
- Dimensions: 80mm(L) × 45mm(W) × 30mm(H)
- Seal material: FKM (Fluorocarbon Rubber) standard / EPDM optional
- Body material: Brass with nickel plating
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Protection rating: IP67 (connector included)
- Flow coefficient (Cv): 0.65
- Port thread depth: 10mm
High-flow compact solenoid valve with manual override function, featuring corrosion-resistant construction and bubble-tight shutoff. The direct-acting design ensures reliable operation even at low differential pressures. Includes DIN-type connector with reverse polarity protection and surge suppression. Compatible with pneumatic and hydraulic systems requiring frequent cycling (up to 100,000 cycles/hour).
- Industrial cleaning equipment fluid control
- Medical device liquid dispensing systems
- Coolant control in CNC machining centers
- Water treatment chemical dosing systems
- Beverage production line flow regulation
- Semiconductor wet process equipment
Installation guidelines:
Mount in any orientation except coil-down position. Install a 10μm filter upstream.
For liquid applications, ensure system pressure remains above 0.05MPa to prevent
cavitation. Use thread sealant (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | 2LH03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
