Airtac 2LH Fluid Solenoid Valve 2LH03008EI
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03008EI Fluid Solenoid Valve Technical Details
- Model: 2LH03008EI
- Type: 3-position 5-way closed center (pneumatic pilot operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–0.7 MPa (7-100 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Weight: 298g ±5g (including coil)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Flow capacity: 1200 l/min (ANR)
- Seal materials: HNBR/FKM composite
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤20ms (at 0.5MPa)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection class: IP67 (dust/water resistant)
- Cycle life: 50 million operations
High-flow proportional control valve with position feedback capability, featuring aluminum alloy body with hard anodized coating. Designed for precise fluid regulation in closed-loop systems. Requires 5μm filtered dry air/liquid and 0.1μm exhaust filter. Compatible with ISO 8573-1 air quality standards.
- Automated liquid dispensing systems
- Beverage filling line pressure control
- Semiconductor cooling fluid management
- Hydraulic system pilot stages
- Medical gas mixing stations
Installation guidelines:
Mount horizontally with flow arrow alignment. Maintain minimum 15mm
clearance for heat dissipation. Use M4 mounting screws (torque ≤1.2N·m).
Pre-flush system before commissioning.
| Property | Property Value |
|---|---|
| sku | 2LH03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
