Airtac 2LH Fluid Solenoid Valve 2LH05010C
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH05010C Fluid Solenoid Valve Technical Details
- Model: 2LH05010C
- Valve type: 2-position, 2-way normally closed (direct-acting)
- Port connection: G1/2" BSPP (ISO228 standard)
- Fluid compatibility: Water, air, light oils (ISO VG32 or below)
- Operating pressure: 0.02–1.0 MPa (vacuum to 10 bar)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 5.5W (DC), 6.5VA (AC)
- Response time: ≤15ms (open/close cycle)
- Seal material: EPDM rubber (standard), optional FKM for chemical resistance
- Temperature range: -5℃ to 80℃ (fluid/ambient)
- Protection class: IP67 (dust/water resistant)
- Weight: 480g ±5% (without fittings)
- Dimensions: 78mm(L) × 52mm(W) × 65mm(H) (body only)
- Port thread depth: 12mm engagement length
High-flow fluid control valve with reinforced stainless steel plunger system, designed for aggressive duty cycles in liquid media applications. Features zero differential pressure operation capability and surge protection circuitry. Includes manual override button for system priming. Requires 25μm filtration upstream.
- Coolant circulation systems in CNC machining centers
- Reverse osmosis water treatment plants
- Automated beverage dispensing/carbonation systems
- Hydraulic oil cooling loop control
- Medical sterilization equipment steam control
Installation protocol:
Mount horizontally with ports downward to prevent sediment accumulation.
Always bleed system pressure before servicing. Pipe joint sealant must
be oxygen-resistant type (PTFE tape prohibited).
| Property | Property Value |
|---|---|
| sku | 2LH05010C |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
