Airtac 2S Fluid Control Valve 2S05010A
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010A Fluid Control Valve Specifications
- Model: 2S05010A
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (with connector)
- Dimensions: 56mm(L) × 32mm(W) × 45mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Flow capacity: 850 l/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve featuring low-hysteresis spool design and dual electromagnetic coils. Optimized for precise pressure regulation in dynamic systems, with gold-plated connectors for stable signal transmission. Includes manual override button for emergency operation. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Automated production line clamping systems
- CNC machine tool pneumatic circuits
- Beverage filling station pressure regulation
- Lithium battery manufacturing vacuum control
- Textile machinery air cylinder sequencing
Installation note:
Install with vibration-damping mounts in high-frequency environments.
Maintain 0.5m minimum clearance from high-voltage cables (>200V).
Lubricate pilot valve stem monthly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2S05010A |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
