Airtac 2S Fluid Control Valve 2S05015F
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015F Fluid Control Valve Technical Details
- Model: 2S05015F
- Type: 5-port 3-position closed center (Pilot-operated)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 680g ±5% (including solenoid coils)
- Dimensions: 58mm(L) × 45mm(W) × 120mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Temperature range: -10℃ to 80℃ (with anti-freeze measures below 0℃)
- Flow capacity: 850 L/min (ANR) at 0.5 MPa
- Response time: ≤50ms (at rated voltage)
- Protection rating: IP67 (dustproof and waterproof)
- Manual override: Built-in emergency manual operator
High-flow directional control valve with closed-center functionality, engineered for precise mid-position cutoff in pneumatic systems. Features dual solenoid operation with LED status indicators and surge protection circuitry. Requires 5μm filtered lubricated air (ISO 8573-1 class 3) for optimal performance.
- Automated assembly line clamping/unclamping sequences
- Plastic injection molding machine cylinder control
- Material handling systems with safety interlocks
- Textile machinery with multi-position actuator requirements
- Semiconductor manufacturing vacuum/pressure switching
Installation guidelines:
Mount using M4 screws with vibration-proof washers. Maintain minimum 20mm
clearance below valve for exhaust airflow. Use shielded cables for solenoid
connections in high EMI environments. Perform monthly lubrication checks
in continuous operation scenarios.
| Property | Property Value |
|---|---|
| sku | 2S05015F |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
