Airtac 2SH High Pressure Solenoid Valve 2SH05010E
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010E High-Pressure Solenoid Valve Specifications
- Model: 2SH05010E
- Type: 2-position, 5-port direct-acting (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.5–16 MPa (72–2320 psi)
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with coil)
- Dimensions: 80mm(L) × 55mm(W) × 105mm(H)
- Seal material: Fluorocarbon rubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 150℃ (FKM seals)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤15ms (at 1MPa)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port thread depth: 12mm (male thread)
- Max flow rate: 1800NL/min (ANR, at 0.7MPa)
Heavy-duty solenoid valve engineered for extreme pressure environments, featuring forged brass body construction with chrome-plated spool. Incorporates pressure-balanced poppet design for reliable switching under load. Includes manual override and surge protection circuitry. Requires ISO 8573-1:2010 Class 3.4.2 compressed air quality.
- Hydraulic system pilot controls
- High-pressure air compressors (20-30HP systems)
- CNC machine tool clamping mechanisms
- Industrial cleaning equipment (200-300 bar systems)
- Plastic injection molding machines
- Test bench pressure regulation systems
Installation requirements:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm minimum clearance for heat dissipation.
Pipe connections must use PTFE tape or liquid sealant (torque ≤35N·m).
| Property | Property Value |
|---|---|
| sku | 2SH05010E |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
