Airtac 2ST Fluid Control Valve 2ST03006A
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006A Fluid Control Valve Specifications
- Model: 2ST03006A
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Flow coefficient (Cv): 1.2
- Response time: ≤30ms (at 0.5MPa)
- Weight: 320g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: NBR (FKM available for high-temp)
- Temperature range: -10℃ to 60℃ (extended to 80℃ with FKM seals)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual solenoid operation, featuring brass body construction for corrosion resistance. Designed for precise bi-directional actuator control in industrial automation. Includes manual override and surge suppression circuitry. Requires 5μm filtered compressed air with oil mist ≤1mg/m³.
- Pneumatic cylinder sequencing in assembly lines
- Clamping/unclamping mechanisms in CNC machinery
- Material handling systems with dual-action cylinders
- Textile machinery air circuit control
- Bottle capping/packaging equipment
Installation note:
Mount with vibration-damping brackets in high-cycle applications (>5Hz).
Maintain 20mm clearance below valve for coil heat dissipation.
Use PTFE tape on ports with clockwise tightening (15-20Nm torque limit).
| Property | Property Value |
|---|---|
| sku | 2ST03006A |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC220V |
