Airtac 2ST Fluid Control Valve 2ST03006B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006B Fluid Control Valve Specifications
- Model: 2ST03006B
- Type: 5-port 2-position (5/2-way) solenoid valve
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤25ms (energized), ≤35ms (de-energized)
- Flow capacity: 0.5 Cv (Kv≈0.43)
- Seal material: Nitrile Butadiene Rubber (NBR) with FKM optional
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 52mm(W) × 43mm(H)
- Port thread depth: 12mm (main ports), 9mm (pilot ports)
- Protection class: IP67 (coil), IP40 (valve body)
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
High-flow directional control valve with aluminum alloy body and manual override. Features dual-pressure operation capability and surge protection circuitry. Optimized for applications requiring rapid cycling (up to 5Hz) with 10 million minimum mechanical life cycles. Requires 5μm filtered compressed air with max 1% relative humidity.
- Automated production line actuators
- Plastic injection molding machine clamps
- Textile machinery cylinder control
- Automotive tire assembly systems
- Food processing pneumatic diverters
Installation guidelines:
Mount horizontally with arrow aligned to flow direction.
Use copper-free anti-vibration washers. Allow 15mm clearance
below valve for condensate drainage. Perform monthly
lubrication checks in high-cycle applications.
Critical note:
Not compatible with phosphate ester-based lubricants.
Always install downstream pressure regulator when
using gas media other than compressed air.
| Property | Property Value |
|---|---|
| sku | 2ST03006B |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
