Airtac 2ST Fluid Control Valve 2ST03006C
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03006C Fluid Control Valve Specifications
- Model: 2ST03006C
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 300g ±5% (including coil)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Seal material: FKM (Fluorocarbon Rubber) for chemical resistance
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: ≤2.5W (DC models), ≤4.5VA (AC models)
- Protection rating: IP67 (dustproof and temporary immersion protection)
- Flow coefficient (Cv): 1.2 (at 7 bar)
- Max operating cycles: 10 million (under rated conditions)
The 2ST03006C features a rugged aluminum alloy body with chrome-plated brass core components, designed for precise fluid control in high-cycle applications. Its low-hysteresis design ensures consistent flow regulation even with rapid actuation cycles. The valve operates with a distinctive "click" feedback for tactile confirmation of switching states.
- Automated production line pneumatic circuits
- Medical device gas control systems
- Beverage dispensing equipment
- Semiconductor manufacturing vacuum/pressure control
- Textile machinery air flow management
- Packaging machine cylinder sequencing
Installation Best Practices:
Mount with vibration-damping brackets in high-frequency applications.
For liquid applications, maintain downward port orientation to prevent
pooling. Always install upstream 5μm filter and lubricator when using
with compressed air systems. Recommend torque values: 12-15N·m for port
connections using PTFE tape.
| Property | Property Value |
|---|---|
| sku | 2ST03006C |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
