Airtac 2ST Fluid Control Valve 2ST03008B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008B Fluid Control Valve Technical Details
- Model: 2ST03008B
- Type: 2-position 5-way pilot-operated solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Maximum flow rate: 1,200 NL/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 1.8W (DC), 2.2VA (AC)
- Body material: Die-cast aluminum alloy (anodized surface)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Ambient temperature range: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Response time: ≤25ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Weight: 680g ±5% (including coil)
- Dimensions: 58mm(W) × 60mm(H) × 128mm(L)
The 2ST03008B features dual solenoid operation with manual override capability, designed for high-speed pneumatic systems requiring bidirectional control. Its optimized flow path reduces pressure drop by 18% compared to previous generations. The valve incorporates a copper-free aluminum body meeting RoHS standards, with shock-resistant construction (up to 30G impact tolerance). Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- High-speed packaging machine cylinder control
- Automated assembly line clamping mechanisms
- Textile machinery air circuit switching
- Plastic injection molding machine ejectors
- Semiconductor wafer handling robots
Installation guidelines:
Mount horizontally with coil axis vertical (±15° tolerance). Maintain minimum
20mm clearance around exhaust ports for proper ventilation. Use M5 mounting
screws with 0.49-0.69N·m torque. Perform weekly exhaust port cleaning in
high-particulate environments.
| Property | Property Value |
|---|---|
| sku | 2ST03008B |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
