Airtac 2ST Fluid Control Valve 2ST03008EI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008EI Fluid Control Valve Technical Details
- Model: 2ST03008EI
- Type: 2-position 3-way (2ST series), normally closed
- Port configuration: PT1/4 (G1/8 optional with adapter)
- Operating pressure range: 0.1–0.8 MPa
- Max flow capacity: 650 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature tolerance: -20℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Port thread depth: 10mm (minimum engagement)
- Protection rating: IP67 (coil), IP40 (valve body)
High-flow proportional control valve with integrated pilot mechanism, featuring brass alloy body with electroless nickel plating for corrosion resistance. Designed for precise medium control in high-cycle applications, with surge protection circuitry for coil longevity. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Beverage filling line pressure modulation systems
- Lithium battery production gas control
- Semiconductor wafer handling vacuum/pressure switching
- Textile machinery pneumatic tension control
- Automated test equipment sequence valves
Mounting protocol:
Install with vibration-damping mounts in high-frequency environments.
Maintain 15° maximum deviation from vertical orientation.
Allow 20mm clearance below valve for condensate drainage.
Torque limit: 2.5N·m on port threads.
| Property | Property Value |
|---|---|
| sku | 2ST03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC24V |
