Airtac 2ST Fluid Control Valve 2ST05010A
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010A Fluid Control Valve Technical Details
- Model: 2ST05010A
- Type: 2-position 5-way monostable (single solenoid)
- Port configuration: 5 ports/2 positions
- Port thread: G1/8 (ISO228 standard)
- Operating pressure range: 0.15–0.8 MPa
- Voltage variants: DC12V, DC24V, AC110V, AC220V (±10%)
- Weight: 320g ±5g (with solenoid)
- Dimensions: 58mm(L) × 42mm(W) × 76mm(H)
- Seal material: HNBR hydrogenated nitrile (oil-resistant)
- Temperature tolerance: -10℃ to 80℃ (non-freezing)
- Flow capacity: 750 l/min (ANR standard)
- Response time: ≤30ms (at 0.5MPa)
- Protection class: IP67 (dust/water resistant)
- Manual override: Built-in push-button actuator
High-flow directional control valve with optimized spool geometry for rapid cylinder reversal. Features dual-color LED status indicator (red/green) and surge protection circuitry. Compatible with ISO 15407-1 standard pneumatic systems. Requires 5μm filtration and lubricated air (ISO 8573-1 class 4).
- Automated assembly line actuator control
- Plastic injection molding machine clamps
- Material handling cylinder sequencing
- Textile machinery tension control systems
- Automotive paint shop automation
Installation guidelines:
Mount with M5 screws (torque ≤1.2N·m). Maintain minimum 20mm
clearance below valve for exhaust flow. Use locking-type connectors
for vibration-prone environments. Perform monthly manual cycling
in low-usage applications.
| Property | Property Value |
|---|---|
| sku | 2ST05010A |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC220V |
