Airtac 2ST Fluid Control Valve 2ST05010E
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010E Fluid Control Valve Specifications
- Model: 2ST05010E
- Type: 2-position, 5-port direct-acting solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–0.8 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 215g ±5g
- Dimensions: 58mm(L) × 35mm(W) × 44mm(H)
- Seal material: Heat-resistant NBR (optionally available in FKM for high-temp applications)
- Temperature range: -10℃ to 80℃ (extendable to 120℃ with FKM seals)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement)
High-speed bistable valve featuring dual-coil latching design for energy-efficient operation. The optimized spool structure ensures stable switching under pressure fluctuations. Compatible with ISO 15407-1 standards, with gold-plated terminals for enhanced corrosion resistance in humid environments.
- High-cycle pneumatic presses and stamping machines
- Automated assembly line clamping systems
- Textile machinery cylinder control
- Beverage filling equipment with CIP cleaning
- Semiconductor wafer handling robots
Installation guidelines:
Maintain horizontal mounting orientation for optimal drainage.
Use vibration-damping brackets in high-frequency applications.
Lubricate with ISO VG32 turbine oil if operated in dry conditions.
| Property | Property Value |
|---|---|
| sku | 2ST05010E |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC24V |
