Airtac 2ST Fluid Control Valve 2ST05010EI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010EI Fluid Control Valve Technical Details
- Model: 2ST05010EI
- Type: 5-port 3-position closed center (double solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.7 MPa
- Voltage variants: DC24V (±10%), AC220V (50/60Hz)
- Weight: 350g ±5% (including connectors)
- Dimensions: 65mm(L) × 45mm(W) × 85mm(H)
- Seal material: Heat-resistant FKM (fluorocarbon rubber)
- Temperature tolerance: -5℃ to 80℃ (non-freezing)
- Flow capacity: 500 L/min (ANR standard)
- Response time: ≤20ms (at 0.5MPa)
- Port thread depth: 12mm (tapered pipe thread)
- Protection class: IP67 (dust/water resistant)
- Service life: 10 million cycles (under rated conditions)
High-flow proportional control valve with dual-coil redundancy, featuring zero-leakage spool design and copper-free aluminum alloy body. Optimized for precise directional control in hydraulic hybrid systems. Includes surge protection circuitry and LED operation indicators. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Multi-axis CNC machine tool clutches
- Automotive assembly line robotic arms
- Plastic injection molding machine hydraulics
- Food processing pneumatic actuators
- Lithium battery production line automation
Installation guidelines:
Mount horizontally with manifold brackets (torque ≤1.5Nm).
Maintain 15mm clearance below valve for heat dissipation.
Lubricate with ISO VG32 hydraulic oil if used in high-cycle (>5Hz) operations.
| Property | Property Value |
|---|---|
| sku | 2ST05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC24V |
