Airtac 2ST Fluid Control Valve 2ST05015A
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05015A 2-Way Fluid Control Valve Technical Details
- Model: 2ST05015A
- Type: 2-position 5-port direct acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.1 - 0.8 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.65 kg ±5%
- Dimensions: 100mm(L) × 50mm(W) × 45mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature tolerance: -5℃ to 80℃ (non-freezing)
- Response time: ≤20ms (at rated voltage)
- Protection class: IP65 (dust-tight & protected against water jets)
- Cv value: 1.2 (flow coefficient)
- Maximum flow rate: 500 l/min (ANR)
- Port thread material: Nickel-plated brass
- Coil insulation class: Class F (155℃)
- Manual override: Optional (adds 8mm to height)
- Compatible fluids: Compressed air (lubricated/non-lubricated), inert gases
The 2ST05015A features a robust electromagnetic actuator with copper-clad aluminum coil winding, designed for high-cycle applications requiring precise directional control. Its zero-pressure differential design enables reliable switching even at system startup. The valve body incorporates pressure-balanced spool technology for reduced actuation force and improved seal longevity.
- Pneumatic cylinder sequencing in packaging machinery
- Air supply switching for automotive assembly line tools
- Cleanroom-compatible medical device pneumatic systems
- Batch processing valves in food-grade air systems
- Laboratory equipment requiring rapid valve cycling
Installation protocol:
Mount in vibration-free locations using M4 mounting screws (not included).
Maintain horizontal orientation for optimal drainage. Use 5μm filtration
upstream and apply thread sealant only on male ports. Allow 15-minute
stabilization period after installation before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | 2ST05015A |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC220V |
