Airtac 2ST Fluid Control Valve 2ST05015F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05015F Fluid Control Valve Technical Details
- Model: 2ST05015F
- Type: 2-position 5-way pilot-operated solenoid valve
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (at rated voltage)
- Flow capacity: 850 L/min (Cv=1.3 at 0.5MPa)
- Seal materials: HNBR (Hydrogenated Nitrile) main seals, FKM (Viton®) optional
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 420g ±5% (excluding accessories)
- Dimensions: 56mm(W) × 53mm(H) × 120mm(L)
- Protection class: IP67 (dustproof and waterproof immersion up to 1m)
- Electrical connection: DIN43650 Form A connector
- Port thread depth: 12mm engagement length
High-flow proportional control valve with optimized spool geometry for precise mid-position control. Features copper-free aluminum alloy body with hard anodized finish for chemical resistance. Integrated surge suppression protects coil from voltage spikes. Requires 5μm filtration for maximum service life.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum pump control in semiconductor handling
- Dual-pressure regulation for injection molding machines
- Automated liquid dispensing systems (compatible with ISO 32 hydraulic fluid)
- Mobile hydraulic controls in agricultural machinery
Maintenance protocol:
Lubricate spool shaft with ISO VG32 oil every 2 million cycles.
Use thread sealant (Loctite 5452 recommended) during installation
to prevent air leakage. Maximum allowable mounting torque: 18 N·m.
| Property | Property Value |
|---|---|
| sku | 2ST05015F |
| Port Size | PT 1/2 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC12V |
