Airtac 2SX Fluid Control Valve 2SX05010AI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010AI Fluid Control Valve Specifications
- Model: 2SX05010AI
- Type: 3-position, 5-port directional control valve (closed center)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 850 L/min (Cv=1.5)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 62mm(W) × 45mm(H) × 135mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) for improved chemical resistance
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 100℃)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (dust tight and protected against immersion up to 1m)
- Port thread depth: 12mm (minimum engagement required)
High-flow proportional control valve with closed-center spool design, optimized for precision pressure regulation in industrial automation systems. Features corrosion-resistant aluminum alloy body with hard anodized coating and integrated silencer. Requires 5μm filtered air supply (ISO 8573-1 class 4) and lubricated air (ISO 32 equivalent oil mist).
- Pneumatic cylinder speed control in assembly lines
- Vacuum generator pressure regulation
- Medical gas mixing systems
- Food processing equipment (NSF-H1 compliant grease option available)
- Semiconductor manufacturing actuators
- Automated packaging machinery
Installation guidelines:
Mount horizontally with arrow marking aligned to flow direction.
Maintain 20mm clearance below valve for heat dissipation.
Use copper-free anti-seize compound on threads.
Maximum allowable vibration: 2.5G at 10-500Hz.
| Property | Property Value |
|---|---|
| sku | 2SX05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
