Airtac 2SX Fluid Control Valve 2SX05010EI
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010EI Fluid Control Valve Specifications
- Model: 2SX05010EI
- Type: 5/2-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (Cv=1.2)
- Weight: 320g ±5% (including coil)
- Dimensions: 54mm(L) × 34mm(W) × 72mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dustproof/waterproof)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual solenoid operation, featuring manual override and LED status indicator. The aluminum alloy body with hard anodized treatment ensures durability in humid environments. Designed for applications requiring bi-directional actuation with position memory function.
- Industrial automation: Cylinder sequencing in assembly lines
- Packaging machinery: Double-acting cylinder control
- Medical equipment: Sterilization chamber door mechanisms
- Food processing: Pneumatic actuator control in washdown areas
- Semiconductor manufacturing: Vacuum/pressure switching systems
Installation notes:1. Use M3 mounting screws with 0.49–0.64N·m torque
2. Maintain 15mm clearance below valve for tubing access
3. Lubricate with ISO VG32 turbine oil if used in dry air systems
4. Perform monthly manual cycling during maintenance shutdowns
| Property | Property Value |
|---|---|
| sku | 2SX05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
