Airtac 2SX Fluid Control Valve 2SX05010F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010F Fluid Control Valve Specifications
- Model: 2SX05010F
- Type: 2-position 5-way solenoid valve (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 1,200 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 56mm(L) × 45mm(W) × 78mm(H)
- Seal material: FKM fluorocarbon (standard) / EPDM optional
- Temperature range: -5℃ to 80℃ (with FKM seals)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
- Service life: ≥10 million cycles
High-flow proportional control valve with dual-coil latching design, featuring brass body construction with anti-vibration treatment. The optimized spool geometry enables precise flow regulation (±2% repeatability) and low hysteresis. Compatible with compressed air, inert gases, and light hydraulic fluids (ISO VG32 or thinner).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum pump control systems
- Beverage filling machine flow regulation
- Textile machinery tension control
- Semiconductor wafer handling robots
- Water treatment plant pneumatic actuators
Installation note:
Install with 50mm clearance above valve for coil replacement. Use flexible tubing for
vibration-prone applications. Lubricate seals with ISO VG32 oil if using dry air.
Critical:
Maintain air quality with 5μm filter and automatic drain. Avoid rapid
pressure fluctuations exceeding 0.3 MPa/sec to prevent spool seizure.
| Property | Property Value |
|---|---|
| sku | 2SX05010F |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
