Airtac 2SX Fluid Control Valve 2SX05015F
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05015F Fluid Control Valve Technical Specifications
- Model: 2SX05015F
- Type: 5-port 3-position closed center (Double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V/220V (±10% 50/60Hz)
- Flow capacity: 1,200 NL/min (ANR at 0.5MPa)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 42mm(W) × 76mm(H)
- Seal material: Nitrile Butadiene Rubber (NBR) standard (FKM optional)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Response time: ≤25ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤10% of rated voltage
High-flow directional control valve with center-block function, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual solenoid configuration enables precise mid-position shutoff control, with integrated surge suppression diodes for electrical protection. Designed for ISO 15407-1 compliance with 5 million cycle durability rating.
- Injection molding machine clamp cylinder control
- Automated assembly line positioning systems
- Textile machinery pneumatic circuits
- Food processing equipment with clean air requirements
- Hydraulic pilot control systems
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (max torque 2.0N·m).
Maintain minimum 30mm clearance below valve for manifold access.
Use 5-40μm filtration with automatic drain. Lubrication not required but compatible with ISO VG32 turbine oil if used.
