Airtac 2WT Extra High Flow Solenoid Valve 2WT030-06-A
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT030-06-A High Flow Solenoid Valve Specifications
- Model: 2WT030-06-A
- Type: 5/3-way double solenoid (closed center)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: Cv=2.5 (Kv=2.8)
- Weight: 520g ±5%
- Dimensions: 76mm(L) × 42mm(W) × 85mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 120℃)
- Power consumption: 3.5W (AC), 3.8W (DC)
- Protection rating: IP67 (dustproof and temporary immersion resistant)
- Response time: ≤15ms (exhaust to actuation)
- Max cycling rate: 5Hz
High-flow industrial solenoid valve engineered for demanding pneumatic systems requiring rapid cycling and large air volume control. Features triple-coil electromagnetic design for stable actuation under pressure fluctuations. The hardened aluminum alloy body withstands vibration up to 25Hz frequency. Requires 25μm filtered dry air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Plastic injection molding machine clamping units
- Automotive tire assembly line actuators
- High-speed packaging machinery with blow-off systems
- Foundry equipment pneumatic circuits
- Paper mill air knife positioning systems
Installation note:
Mount with vibration-damping brackets in high-shock environments. Maintain 15mm clearance
around valve for heat dissipation. Use copper-free anti-seize compound on threaded ports.
Perform monthly manual override tests for critical systems.
| Property | Property Value |
|---|---|
| sku | 2WT030-06-A |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC220V |
