Airtac 2WT Extra High Flow Solenoid Valve 2WT030-06-B
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT030-06-B High Flow Solenoid Valve Technical Details
- Model: 2WT030-06-B
- Type: 5/3-way direct-operated (center closed position)
- Port size: G1/4 (BSPP thread standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 2000 L/min (ANR) at 0.5 MPa
- Flow coefficient (Cv): 2.3
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -20℃ to 80℃ (with intermittent peaks to 100℃)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Weight: 580g ±3% (including coil)
- Dimensions: 82mm(L) × 45mm(W) × 78mm(H) (excluding connectors)
- Port alignment: 30mm center-to-center spacing
- Housing material: Die-cast aluminum with epoxy coating
Engineered for industrial-grade pneumatic systems requiring rapid large-volume airflow control. Features triple-position functionality (pressure/vent/exhaust) with manual override capability. The optimized spool design reduces pressure drop by 18% compared to previous generation models. Requires 5μm filtered lubricated or non-lubricated air (ISO 8573-1 class 3).
- High-speed packaging machinery cylinder control
- Plastic injection molding machine clamp systems
- Automated foundry equipment actuator banks
- Lithium battery production line vacuum/pressure switching
- CNC machine tool pneumatic brake systems
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Use vibration-damping brackets in mobile applications.
Maintain minimum 15mm clearance around valve body for heat dissipation.
Parallel wiring of multiple valves requires individual circuit protection.
| Property | Property Value |
|---|---|
| sku | 2WT030-06-B |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC24V |
