Airtac 2WT Extra High Flow Solenoid Valve 2WT030-06-C
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High-Flow Solenoid Valve 2WT030-06-C Technical Details
- Model: 2WT030-06-C
- Type: 5/3-way double solenoid (closed center)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow capacity: 2000 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (at 0.5MPa)
- Weight: 1.2 kg ±5%
- Dimensions: 120mm(L) × 72mm(W) × 62mm(H)
- Valve body material: Aluminum alloy (anodized)
- Seal material: Heat-resistant HNBR rubber
- Temperature range: -10℃ to 80℃ (with 5℃ safety margin)
- Power consumption: 4.5W (DC24V), 5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high-flow solenoid valve engineered for demanding pneumatic systems requiring rapid large-volume air control. Features triple-coil protection against overvoltage/overcurrent and optimized flow paths achieving Cv=3.8. The dual-chamber design ensures stable mid-position closure with zero leakage. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.4 purity standards.
- High-speed packaging machinery cylinder control
- Injection molding machine clamp mechanisms
- Automotive tire assembly pneumatic systems
- Industrial vacuum generator switching
- Foundry equipment air blast control
Installation protocol:
Mount with vibration-damping brackets in horizontal orientation only.
Maintain minimum 15cm clearance from heat sources. Use M3.5 torque-limited screws
(max 0.8N·m) for manifold mounting. Perform weekly manual override tests.
| Property | Property Value |
|---|---|
| sku | 2WT030-06-C |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
