Airtac 2WT Extra High Flow Solenoid Valve 2WT030-08-E
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High-Flow Solenoid Valve 2WT030-08-E Technical Details
- Model: 2WT030-08-E (Direct-acting, monostable)
- Valve type: 5/2-way (double solenoid optional)
- Port size: PT3/8 (G3/8" BSPP thread standard)
- Flow capacity: 2000 L/min (Cv=5.0 at 0.5MPa)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage variants: DC12V(±10%), DC24V(±10%), AC110V(±10% 50/60Hz), AC220V(±10% 50/60Hz)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Body material: Anodized aluminum alloy (hard coating)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Protection class: IP67 (dust/water resistant)
- Weight: 780g ±5% (without connectors)
- Dimensions: 100mm(L) × 62mm(W) × 85mm(H) (excluding mounting brackets)
- Port thread depth: 12mm (minimum engagement required)
- Max cycling rate: 5Hz (300 cycles/minute)
Industrial-grade high-flow solenoid valve engineered for demanding pneumatic systems requiring rapid actuation and large volume air transfer. Features optimized flow paths reducing pressure drop by 18% compared to standard models. The reinforced coil structure withstands voltage fluctuations in harsh environments. Compatible with ISO 15407-1 standards.
- Plastic injection molding machine clamp units
- Automotive tire assembly pneumatic circuits
- High-speed packaging line actuators
- Foundry equipment cylinder control
- Railway braking system simulation rigs
Installation requirements:
Requires 25A-rated connectors for power supply. Maintain minimum 50mm
clearance below valve for condensate drainage. Lubricate with ISO VG32
turbine oil if using non-lubricated air systems. Avoid mounting near
high-frequency inverters (>10kHz).
| Property | Property Value |
|---|---|
| sku | 2WT030-08-E |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC24V |
