Airtac 2WT Extra High Flow Solenoid Valve 2WT030-08-F
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT030-08-F High Flow Solenoid Valve Specifications
- Model: 2WT030-08-F
- Type: 5/3-way double solenoid (center exhaust)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Flow capacity: 1600 L/min (ANR) at 0.5 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (coil insulation class F)
- Weight: 2.4 kg (with connectors)
- Dimensions: 145mm(L) × 70mm(W) × 105mm(H)
- Seal material: HNBR rubber (fluorocarbon optional)
- Temperature range: -5℃ to 80℃ (with anti-freeze measures)
- Response time: ≤25ms (excitation), ≤35ms (de-excitation)
- Power consumption: 5.5W (DC24V), 6.5VA (AC220V)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 13mm (3/8-19 UNF)
Industrial-grade high-flow solenoid valve featuring dual-coil latching design for energy efficiency. Optimized flow path geometry reduces pressure drop by 18% compared to standard models. Compatible with ISO 15407-1 standards, with brass body and chrome-plated spool for enhanced corrosion resistance. Requires 25μm filtered air with oil mist lubrication (ISO VG32 recommended).
- High-speed pressurization systems in injection molding machines
- Pneumatic conveyor control in bulk material handling
- Automotive tire inflation systems
- Industrial robot end-effector controls
- Large-scale pneumatic actuator arrays
Installation note:
For optimal performance, install with downward-facing exhaust ports.
Use anti-vibration mounts in applications exceeding 15Hz mechanical frequency.
Minimum 30cm straight piping required upstream for flow stabilization.
| Property | Property Value |
|---|---|
| sku | 2WT030-08-F |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | DC12V |
