Airtac 2WT Extra High Flow Solenoid Valve 2WT03006AI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High Flow Solenoid Valve 2WT03006AI Technical Details
- Model: 2WT03006AI
- Series: 2WT Super High Flow Solenoid Valve
- Valve type: 5-port/3-position direct acting
- Port size: PT3/4 (G3/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 5W (DC), 6.5VA (AC)
- Flow capacity: 6500 L/min (ANR) at 0.5MPa
- Weight: 1.2 kg (including coil)
- Dimensions: 125mm(L) × 90mm(W) × 65mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Valve body material: Anodized aluminum alloy
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection class: IP67 (coil), IP40 (valve body)
- Response time: ≤30ms (at rated voltage)
- Coil insulation class: Class F (155℃)
- Port thread depth: 12mm (minimum engagement)
Engineered for demanding industrial applications requiring massive airflow control, the 2WT03006AI features an optimized flow path design achieving 35% higher throughput than standard models. Its reinforced piston structure withstands 2 million cycles under full load. The dual-coil heat dissipation design prevents overheating during continuous operation. Requires 5μm filtered compressed air with lubricator (ISO 8573-1 class 4).
- High-speed plastic injection molding machines
- Pneumatic conveyor systems for bulk materials
- Automotive manufacturing paint line actuators
- Industrial boiler combustion air control
- Large-scale pneumatic press circuits
- Semiconductor fab compressed air distribution
Installation protocol:
Mount horizontally with manifold brackets (axial vibration <2G).
Maintain 15cm clearance above valve for heat dissipation.
Use copper-free anti-seize compound on port threads.
Parallel installation of multiple valves requires 20mm spacing minimum.
| Property | Property Value |
|---|---|
| sku | 2WT03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC220V |
