Airtac 2WT Extra High Flow Solenoid Valve 2WT03006E
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High Flow Solenoid Valve 2WT03006E Specifications
- Model: 2WT03006E
- Type: 5-port 2-position, double solenoid operated
- Port size: PT3/4 (G3/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Effective flow rate: 2000 L/min (ANR) at 0.5 MPa
- Weight: 1.5 kg (3.3 lbs)
- Dimensions: 130mm(L) × 90mm(W) × 105mm(H)
- Seal material: HNBR rubber (high-temperature nitrile)
- Temperature range: -5℃ to 60℃ (23℉ to 140℉)
- Response time: ≤30ms (open/close at rated voltage)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 12mm (minimum engagement)
- Max cycling rate: 5Hz (300 cycles/minute)
The 2WT03006E features an optimized flow path design with 35% larger effective cross-section than standard models, achieving industry-leading CV value of 3.8. Its reinforced stainless steel armature and copper-aluminum composite coil ensure 1 million+ cycle durability. The valve body uses anodized aluminum alloy with triple-layer epoxy coating for chemical resistance.
- High-speed packaging line diverters
- Plastic injection molding machine clamp control
- Automotive tire assembly systems
- Foundry equipment pneumatic circuits
- Paper mill roll positioning mechanisms
Installation guidelines:1. Mount in vibration <50Hz environments using M6 mounting bolts
2. Maintain ambient humidity below 85% RH (non-condensing)
3. Use 10μm precision filter with automatic drain
4. Lubricate with ISO VG32 turbine oil if required
5. Allow 20mm clearance for heat dissipation during continuous operation
| Property | Property Value |
|---|---|
| sku | 2WT03006E |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC24V |
