Airtac 2WT Extra High Flow Solenoid Valve 2WT03006EI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series Ultra-High Flow Solenoid Valve 2WT03006EI
- Model: 2WT03006EI
- Type: 5/2-way double solenoid pilot-operated
- Port size: PT3/4 (G3/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.2kg ±5%
- Dimensions: 150mm(L) × 85mm(W) × 105mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with metal slide guides
- Temperature range: -5℃ to 60℃ (operating fluid)
- Response time: ≤30ms (open/close at 0.5MPa)
- Flow capacity: Cv=18 (Kv=15.5)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 13mm (minimum engagement)
- Max cycling rate: 5Hz (with silencer)
High-performance large-bore solenoid valve engineered for heavy-duty pneumatic systems requiring rapid actuation and massive airflow. Features corrosion-resistant aluminum alloy body with hardened stainless steel spool assembly. Includes manual override and dual redundant coil protection. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- High-speed packaging machinery actuators
- Automotive tire molding presses
- Plastic injection molding clamp systems
- Foundry equipment pneumatic circuits
- Paper mill cylinder positioning
- Robotic material handling arms
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction. Install upstream
moisture separator and downstream speed controller. Allow 50mm clearance
above valve for maintenance access. Perform weekly manual cycling in dusty environments.
| Property | Property Value |
|---|---|
| sku | 2WT03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC24V |
