Airtac 2WT Extra High Flow Solenoid Valve 2WT050-10-B
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-10-B High Flow Solenoid Valve Specifications
- Model: 2WT050-10-B
- Type: 5/2-way direct acting (monostable)
- Port size: G3/8 (NPT3/8 optional)
- Flow capacity: 2200 Nl/min (Cv=3.2)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (50/60Hz)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Operating temperature: -5℃ to 80℃ (no freezing)
- Seal material: Heat-resistant NBR (option: FKM for 120℃)
- Protection rating: IP67 (dustproof & waterproof)
- Mounting style: ISO 5599/1 standard interface
- Weight: 1.65 kg (including coil)
- Dimensions: 130mm(L) × 64mm(W) × 78mm(H)
- Manual override: Optional paddle-type emergency control
- Power consumption: 3.5W (DC), 5.5VA (AC)
Engineered for industrial heavy-duty applications, the 2WT050-10-B features a triple-coil protection system with surge suppression and thermal overload prevention. Its low-hysteresis spool design ensures precise cylinder control even under fluctuating pressures. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- High-speed press machines (300+ cycles/min)
- Plastic injection molding clamp units
- Automotive assembly line pallet changers
- Foundry equipment with thermal shock resistance
- Large-bore pneumatic cylinder control systems
Installation protocol:
Mount horizontally with manifold alignment tolerance ≤0.2mm.
Maintain 15mm clearance on exhaust ports for heat dissipation.
Use M5x0.8 mounting screws with 1.2-1.5N·m torque.
| Property | Property Value |
|---|---|
| sku | 2WT050-10-B |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
