Airtac 2WT Extra High Flow Solenoid Valve 2WT050-10-E
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-10-E High-Flow Solenoid Valve Technical Details
- Model: 2WT050-10-E
- Type: 5/2-way direct-acting (high flow design)
- Port size: G3/8 (ISO 228/1 standard)
- Flow capacity: 2200 NL/min @ 0.5 MPa
- Operating pressure: 0.2–1.0 MPa (max burst pressure 1.5 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤25ms (exhaust to actuation)
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Body material: Anodized aluminum alloy (surface hardness HV80)
- Protection class: IP67 (dust/water resistant)
- Weight: 980g ±2% (without connectors)
- Dimensions: 132mm(L) × 50mm(W) × 68mm(H) (manual override protrusion adds 18mm)
- Port thread depth: 12mm (parallel threads with O-ring seal)
- Coil insulation: Class F (155℃ rated)
High-performance pneumatic valve engineered for industrial heavy-duty applications requiring massive airflow. Features twin-pressure operation capability and manual override function. The optimized flow path design reduces pressure drop by 35% compared to standard models. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Plastic injection molding machine clamp units
- Automotive tire assembly line actuators
- High-speed packaging equipment (＞800 cycles/min)
- Foundry air cylinder control systems
- Pneumatic conveyor diverter valves
Maintenance protocol:
Lubricate spool monthly with ISO VG32 turbine oil (1 drop per port).
Install vibration dampeners when used with reciprocating compressors.
Minimum 15mm clearance required below valve for condensate drainage.
| Property | Property Value |
|---|---|
| sku | 2WT050-10-E |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC24V |
