Airtac 2WX Fluid Solenoid Valve 2WX05010A
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010A Fluid Solenoid Valve Specifications
- Model: 2WX05010A
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Fluid compatibility: Air, water, light oils (ISO VG32 or thinner)
- Max operating pressure: 1.0 MPa
- Min operating pressure: 0.02 MPa (air), 0.1 MPa (liquid)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: FKM (Viton®) standard, optional EPDM or NBR
- Temperature range: -5℃ to 80℃ (with FKM seals)
- Protection rating: IP67 (dustproof and waterproof)
- Weight: 280g ±5% (excluding connector)
- Dimensions: 55mm(L) × 34mm(W) × 45mm(H) (body only)
- Port spacing: 18mm between fluid ports (center-to-center)
- Coil insulation class: Class F (155℃)
High-speed fluid control valve with brass body and reinforced PPS coil housing. Features manual override button for system debugging and low-hysteresis design for precise flow regulation. Compatible with pneumatic and hydraulic systems requiring bi-directional flow control. Requires 25μm filtration for liquid applications.
- Industrial coolant circulation systems
- Beverage dispensing machine flow control
- Analytical instrument reagent switching
- Semiconductor wafer cleaning equipment
- Hydraulic brake release mechanisms
Installation guidelines:
Mount with flow direction arrow aligned to system requirements.
For liquid media, install with coil facing upward to prevent bubble accumulation.
Use copper-free anti-seize compound on threads.
Minimum 500-hour burn-in recommended for critical processes.
| Property | Property Value |
|---|---|
| sku | 2WX05010A |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
