Airtac 2WX Fluid Solenoid Valve 2WX05010F
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010F Fluid Solenoid Valve Specifications
- Model: 2WX05010F
- Type: 5-port 2-position (5/2-way) direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 650 L/min (ANR)
- CV value: 1.3
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Ambient temperature: -5℃ to 80℃ (with 0℃ anti-freeze measures)
- Fluid temperature: 0–60℃
- Body material: Aluminum alloy (anodized surface)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Weight: 320g ±5%
- Dimensions: 52mm(L) × 36mm(W) × 78mm(H)
- Mounting: Sub-base compatible (ISO 5599-1 standard)
- Protection rating: IP67 (coil protection)
- Duty cycle: 100% ED (continuous operation capable)
- Lubrication: Oil mist lubrication required (ISO VG32 equivalent)
High-flow directional control valve with optimized spool geometry for reduced pressure drop. Features dual-chamber sealing technology for leak-proof performance in vacuum/pressure applications. The hardened aluminum body withstands vibration in mobile hydraulic systems. Requires 5μm filtered compressed air with ≤3mg/m³ oil content.
- Pneumatic cylinder reciprocation control in assembly lines
- Vacuum pump switching in packaging machinery
- Air motor direction reversal in conveyor systems
- Process gas flow control in semiconductor manufacturing
- Clamping fixture operation in CNC machining centers
Installation protocol:
Mount with vibration-damping gaskets in high-shock environments.
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Perform manual override test before commissioning.
Critical note:
Not compatible with phosphate ester fluids or chlorinated solvents.
Requires 2-second minimum interval between consecutive actuations for heat management.
| Property | Property Value |
|---|---|
| sku | 2WX05010F |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
