Airtac 2WX Fluid Solenoid Valve 2WX05015F
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05015F Fluid Solenoid Valve Technical Details
- Model: 2WX05015F
- Type: 5/2-way direct acting (monostable)
- Port size: PT1/4 (G1/4 optional)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 l/min (Cv=1.2)
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Coil power: 2.2W (DC), 3.5VA (AC)
- Weight: 300g ±5%
- Dimensions: 40mm(W) × 40mm(H) × 70mm(L)
- Seal material: FKM (Viton) for high temp applications
- Temperature range: -5℃ to 80℃ (fluid/ambient)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port alignment: ISO 5599/1 standard
High-flow solenoid valve with manual override, designed for bidirectional control in pneumatic systems. Features brass body with anodized aluminum coil housing for chemical resistance. Requires 5μm filtration (lubricated or non-lubricated air). Compatible with vacuum applications when using special seals.
- Automated assembly line actuators
- Plastic injection molding machine controls
- Textile machinery tension systems
- Semiconductor wafer handling robots
- Food processing pneumatic circuits (FDA-grade seals optional)
Installation guidelines:
Mount with DIN rail bracket (optional accessory 02-1003).
Maintain ≥15mm clearance below valve for exhaust airflow.
Use copper-free anti-seize compound on threads.
For horizontal mounting, install coil facing upward.
