Airtac 3V100 Solenoid Valve 3V11006NC-X0
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100-06NC-X0 Solenoid Valve Technical Details
- Model: 3V11006NC-X0 (3V100 series)
- Valve type: 3-way, 2-position normally closed (direct-acting)
- Port thread: G1/8 (ISO228 standard)
- Orifice diameter: 2.5mm
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Fluid temperature: 0-60℃
- Viscosity range: ≤21 cSt
- Port alignment: 3-port (P: pressure, A: outlet, R: exhaust)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Body material: Reinforced PBT with UL94 V-0 flame rating
- Weight: 210g ±5g (including coil)
- Dimensions: 50mm (L) × 34mm (W) × 63mm (H)
- Protection class: IP67 (coil), IP40 (valve body)
- Expected lifespan: 30 million cycles (at 2Hz switching frequency)
High-response solenoid valve optimized for low-power pneumatic systems requiring precise air flow control. Features manual override capability through integrated push button and dust-resistant plunger design. Compatible with ISO VG32 hydraulic oil environments. Requires 5μm filtration with water separator.
- Robotic gripper pressure regulation in assembly lines
- CNC machine tool clamping/unclamping sequences
- Beverage filling system pneumatic actuators
- Lithium battery production vacuum control
- Textile machinery air jet looms
Maintenance advisory:
Lubricate moving parts with ISO VG32 turbine oil every 6 months in continuous operation.
Avoid mounting near high-frequency vibration sources (>50Hz) to prevent coil loosening.
| Property | Property Value |
|---|---|
| sku | 3V11006NC-X0 |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
