AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageAC220V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W)
The AirTAC 3V11006NCA-W is a 3-port, 2-position (3/2) solenoid valve in the 3V1 body size with a PT 1/8" port. A 3/2 valve has one supply, one outlet and one exhaust, and it sits in one of two states: it either feeds air to the outlet or vents the outlet to exhaust. This unit is normally closed, so no air reaches the outlet and the downstream line vents to exhaust until the AC220V coil is energised - the position you want for clamps and single-acting cylinders that must release when power is lost.
It is a genuine AirTAC part. The 3V1 family is also offered in a normally open version, five coil voltages, and with a DIN plug or flying-lead electrical entry, and 3V1 manifold bases carry several valves on one shared supply. Pressure, flow and coil power for this series are not in our published data; send us your operating conditions and we will confirm the figures from the manufacturer datasheet.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | AC220V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| AC220V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) Is Used
Pneumatic clamp on a drilling fixture
A spring-return clamp cylinder holds the workpiece while the coil is energised and drops out - literally - the moment power or signal is lost, releasing the part automatically.
Chip-clearing air jet on a machining centre
An on/off blow line sweeps chips out of a milled pocket between cycles, fed only while the NC coil is switched on.
Pilot stage for a large process valve
The 3/2 valve sends or vents the pilot signal to a bigger air-actuated process valve, switching it from a compact solenoid.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) the Right Part?
Choose normally closed when the circuit must lose its air signal whenever the coil is off; choose the normally open version of this body when an outlet must stay fed through a power failure. The PT 1/8" port is the smallest common fitting size here and suits small single-acting cylinders and light blow duties; if the actuator consumes more air, step up to the 1/4" or 3/8" ports in this family. The AC220V coil must match a 220 V AC panel supply, and entry is a DIN plug. For several valves on one air feed, mount them on a 3V1 manifold base and order the valves separately. Flow data for this series is not in our hands, so ask us to check the valve against your actuator before ordering - and if you need published flow and coil power today, the AirTAC 3V2 (1/8" and 1/4" ports) and 3V3 (1/4" port) bodies carry them. A double-acting cylinder is beyond any 3/2 valve; that job needs a 5-port AirTAC 4V valve.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCA-W) FAQ
We do not publish performance numbers for the 3V1 series on this page. Send us your operating pressure and actuator details by RFQ and we will confirm pressure, flow and coil power from the AirTAC datasheet. If you need published figures immediately, the AirTAC 3V2 (1/8" and 1/4" ports) and 3V3 (1/4" port) bodies carry them.
No. A 3/2 valve has only one outlet, which is enough for a spring-return (single-acting) cylinder, a blow line or a pilot signal. A double-acting cylinder needs two outlet lines to pressurise each side in turn, so use a 5-port valve from the AirTAC 4V series.
