Airtac 3V100 Solenoid Valve 3V11006NCAI
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
3V11006NCAI
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pilot Operation: Optional internal pilot or external pilot configurations;
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
Installation guidelines:
For vertical mounting (coil upward), use thread sealant on ports.
Maximum allowable vibration: 50m/s² (5G). Lubricate with ISO VG32
turbine oil if used in dry air systems. Minimum 10,000-hour
maintenance interval under standard conditions.
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100-06NCAI Solenoid Valve Technical Details
- Model: 3V11006NCAI (Full code: 3V100-06NC-AI)
- Valve type: 3/2-way, Normally Closed (Direct-acting)
- Port thread: PT1/8 (BSPP) with M5 sub-port for pressure gauge
- Operating pressure range: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.2W (DC) / 2.5VA (AC)
- Flow coefficient (Cv): 0.14
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Body material: Reinforced PBT with brass core
- Protection class: IP67 (dustproof & temporary immersion)
- Ambient temperature: -20℃ to 60℃ (non-freezing)
- Weight: 185g ±3% (including coil)
- Dimensions: 52mm(L) × 34mm(W) × 65mm(H) (port axis to top)
High-frequency compact solenoid valve optimized for low-power systems, featuring dual-port exhaust design for rapid cycling. The brass-PBT composite construction ensures chemical resistance against mild acids and hydraulic oils. Includes manual override button for system debugging.
Ideal For:
- Beverage dispenser fluid control (coffee machines/soft drink systems)
- 3D printer pneumatic extruder management
- Cleanroom equipment requiring low particulate emission
- Solar-powered irrigation valve clusters
- Mobile HVAC pneumatic actuators
Installation guidelines:
For vertical mounting (coil upward), use thread sealant on ports.
Maximum allowable vibration: 50m/s² (5G). Lubricate with ISO VG32
turbine oil if used in dry air systems. Minimum 10,000-hour
maintenance interval under standard conditions.
| Property | Property Value |
|---|---|
| sku | 3V11006NCAI |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
