Airtac 3V100 Solenoid Valve 3V11006NCB
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100 Series Solenoid Valve 3V11006NCB Technical Details
- Full model code: 3V11006NCB (3V100 platform)
- Valve type: 3/2-way normally closed (direct-acting)
- Port thread: PT1/8 (G1/8 optional)
- Operating pressure range: 0.05–0.8 MPa (7-116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Flow coefficient (Cv): 0.45
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Body material: Die-cast aluminum with anodized finish
- Protection class: IP67 (dustproof & waterproof)
- Electrical connection: DIN43650A standard plug
- Weight: 180g ±5g (without connector)
- Dimensions: 50mm(L) × 34mm(W) × 63mm(H) / 1.97" × 1.34" × 2.48"
High-speed response solenoid valve optimized for low-power systems, featuring brass core tube for enhanced magnetic efficiency. The dual-chamber design minimizes pressure fluctuation during switching. Compatible with vacuum applications (0.05MPa minimum) and rated for 5 million cycles. Requires ISO 8573-1:2010 [4:4:4] class compressed air.
- High-cycle textile machinery actuators
- Semiconductor wafer handling robotics
- Beverage filling line pneumatic control
- Lithium battery production equipment
- Laboratory analytical instrument gas control
Installation guidelines:
Maintain ambient temperature below 55℃ with relative humidity <85% RH.
Use vibration-damping mounts if operating frequency exceeds 5Hz.
Lubricate every 20 million cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 3V11006NCB |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
