AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W)
The AirTAC AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) is a genuine 3-port 2-position (3/2) solenoid valve with 1/8 in ports. A 3/2 valve either feeds its outlet or vents it to exhaust, so it suits single-acting cylinders, air blow, clamping, vacuum switching and pilot duty. We stock this code and confirm its published figures from the datasheet on request.
- Valve type3/2-way (3-port, 2-position)
- Initial stateNormally closed
- Port size1/8 in
- Coil voltageDC24V
- Electrical entryDIN plug (DIN socket type)
- Series3V110
About the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W)
Three ports and two positions define this valve class: supply, outlet and exhaust, with the outlet either fed from supply or dumped to exhaust. In the 3V11006NCB-W, the resting state is normally closed - the outlet stays shut off and vented until the DC24V coil is energised, then supply is connected through. The 1/8in PT port suits compact single-acting cylinders, air guns and small pilot lines.
AirTAC manufactures this valve, and the family behind it covers both NC and NO states, all five coil voltages, two electrical entries and 3V-F manifold bases carrying up to twenty stations. We hold no published performance sheet for this family in-house, so send your enquiry and we will pull the datasheet numbers for you.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) Technical Specifications
| Model | AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) |
|---|---|
| Series | 3V110 |
| Valve type | 3/2-way (3-port, 2-position) |
| Initial state | Normally closed |
| Port size | 1/8 in |
| Thread | PT |
| Coil voltage | DC24V |
|---|---|
| Electrical entry | DIN plug (DIN socket type) |
| Coil power | Confirm from the datasheet — ask us |
| Operating pressure | Confirm from the datasheet — ask us |
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W)
| 3V110 | Body. |
|---|---|
| 1/8 in | Port size. M5, 06 = 1/8 in, 08 = 1/4 in, 10 = 3/8 in. |
| NC | Normally closed: no air at the outlet until the coil is energised. |
| DC24V | Coil voltage. A = AC220V, B = DC24V, C = AC110V, E = AC24V, F = DC12V. |
| — | Electrical entry: I = flying lead, otherwise a DIN plug. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) Is Used
Fixture clamp release
Vent a spring-return clamp on a machining fixture at end of cycle, so the part is never held without control power.
Pilot signal for a process valve
Supply the pilot port of a larger pneumatic process valve on a packaging machine air skid.
Workshop air gun
Feed an on/off air nozzle at a maintenance bench, giving a positive shut-off and a vented line between blows.
Is the AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) the Right Part?
The 1/8in port is the smallest screw-in size on this body, so match it to compact spring-return actuators or blow duties; a larger single-acting cylinder will call for the 1/4in or 3/8in step up. Normally closed is the right pick when the circuit must de-energise to a vented, air-free outlet. This version arrives as a DIN plug valve - fit your own connector - while the I-suffix variants come as flying leads.
DC24V is fixed for this SKU, and a coil cannot be converted to another voltage by rewiring. Since we cannot quote flow for the 3V1 family from our own data, let us check the sizing against your actuator before you order; the documented AirTAC 3V2 and 3V3 valves publish flow and coil power if you need numbers today. Double-acting duty belongs to the AirTAC 4V range.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Match the coil voltage to your controller output.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Wiring by qualified personnel, per AirTAC documentation.
AirTAC 3V110-06 Solenoid Valve, 3V100 Series (3V11006NCB-W) FAQ
Our own records for the 3V1 family do not include a specification sheet, so rather than estimate, we confirm pressure, flow and coil power from the manufacturer datasheet on request. The AirTAC 3V2 and 3V3 series are the documented alternatives if published figures are needed now.
Decide from your fail-safe requirement: NC blocks the outlet and vents it until energised, NO passes air until energised. Also note a 3/2 valve cannot drive a double-acting cylinder - that needs an AirTAC 4V five-port valve.
