Airtac 3V100 Solenoid Valve 3V11006NCBI-W
2. Spool-type structure ensures excellent sealing performance and rapid response characteristics;
3. Dual solenoid version features position memory function for status retention during power interruption;
4. Precision-machined inner bore with specialized surface treatment achieves low friction resistance, minimal actuation pressure requirement, and enhanced operational longevity;
5. Lubrication-free design eliminates maintenance requirements;
6. Integrated manual override facilitates installation commissioning and system diagnostics;
7. Multiple standardized voltage specifications available for global compatibility;
8. Manifold mounting capability enables compact valve grouping solutions for space-constrained applications. Category: Solenoid Valves | Brand: AirTAC | Series: 3V100
AirTAC 3V100-06NC-BI-W Solenoid Valve Specifications
- Model: 3V11006NCBI-W (Full designation: 3V100-06NC-BI-W)
- Valve type: 3-position, 5-way (center closed)
- Operation mode: Double solenoid pilot-operated
- Port size: G1/8 (ISO228/1 standard)
- Thread specification: Rc1/8 (NPT optional)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (excitation), ≤20ms (de-energization)
- Flow capacity: 850 l/min (ANR, at 0.5MPa)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Seal material: Heat-resistant NBR (Nitrile), Viton optional
- Body material: Reinforced PBT with glass fiber
- Protection rating: IP67 (dustproof and waterproof)
- Electrical connection: DIN43650 Form A connector
- Manual override: Built-in push-button (with lockable option)
- Weight: 210g ±5g (excluding connector)
- Dimensions: 54mm(L) × 38mm(W) × 72mm(H) (manifold mounting surface to top)
This tri-stable pneumatic valve boasts a zero-point locking mechanism and shock-resistant coil design, engineered for precision control in high-cycle applications. Its oil-free construction and self-cleaning spool structure minimize maintenance requirements. The valve features surge suppression diodes for electrical protection and includes LED status indication. Requires 5μm filtered lubricated air (ISO8573-1 class 4) with 20-50 cSt oil viscosity.
- Multi-axis robotic end effectors requiring position hold
- Plastic injection molding machine clamp controls
- Automated assembly line tool changers
- Semiconductor wafer handling vacuum/pressure systems
- Food processing equipment with frequent mode switching
Installation guidelines:
Maintain ≤3° deviation from vertical axis during mounting.
Use anti-vibration washers in high-frequency applications.
Allow 15mm clearance above coil for heat dissipation.
Always install downstream lubricator when using non-lubricated air.
- CV value: 1.6 (pressure drop ΔP=0.1MPa)
- Effective area: 18mm² (equivalent orifice diameter)
- Leakage: ≤3 bubbles/min (ISO standardized test)
| Property | Property Value |
|---|---|
| sku | 3V11006NCBI-W |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
